• Diaphragm poppet principle features bubble-tight seal at rest and actuated
  • • Rugged 2- and 3-way valves available in normally open or closed function
    • Available in two high flow constructions, 1/8 and 1/4 PIPE
    • Suitable for inline, base, or panel mounting
    • Large fingertip lever can rotate for positioning
• Convenient 34T Lever Operator offered for Miniature TAC Push Button 2, 3 and 4-Way Valves

• Designed for high production manual workstations
• Compact designs for proximity mounting to work
• Fast cycling/quick exhaust
• Standard or optional brass body suitable for inline, base, or panel mounting
• Popular model 125PLG:
  • • Guarded button prevents accidental actuation and bridging in two-hand control
    • Rugged normally closed valves in 2- or 3-way configurations
    • Air-spring return design assures bubble-tight sealing

• Rugged, reliable diaphragm poppet internal construction
  • • Bubble-tight sealing at rest and actuated
    • Design prevents sticking in harsh environments
    • Available in 2 or 3-Way, Normally Closed or Open, or 4-Way Types
    • 12 Gauge Steel Guard and Base included
• Convenient 34F Foot Operator offered for Miniature TAC Push Button 2, 3 and 4 Way Valves

• Popular 125V, 250V and 501V Valves feature rugged, high flow poppet construction
  • • Unbalanced, air spring return for bubble-tight sealing and reliable shifting
    • 3 Way construction, plug exhaust port for 2-way applications
    • Inline, base, or panel mounting
    • Heavy-duty lever has a positive detent in both positions
    • Lever rotates for convenient positioning
• Dependable 250-4H model designed for excellent three-position, four-way function
• TAC Miniature 10-32 UNF and 1/8 PIPE Toggle Valves available in 2, 3 and 4-Way

Plunger Operated valves achieve high flow operation from its compact body. These valves are available normally closed or open from its compact 1/8 PIPE body construction. Plunger is forgiving with built-in overstroke protection.

TAC Miniature push button valves are rugged enough to operate as a mechanical plunger valve or are ready to accept any of four different mechanical valve operators.

Roller Cam and Roller Ball Operated mechanical valves feature the classic Humphrey diaphragm poppet principle. The unbalanced, air-spring return design assures bubble-tight sealing and reliable operation in the dirtiest environments.

The rugged 2- or 3-way valves are available normally closed or normally open.

Pneumatic Solenoid Valves: The Humphrey Advantage

Humphrey Products’ pneumatic solenoid valves offer design engineers high-flow efficiency in two-way, three-way, and four-way functions. Our valves accommodate nearly any media, including compressed air, vacuum, and inert gases.

Leading manufacturers prefer the compact, efficient and reliable designs of our pneumatic solenoid valves, and they also benefit from our application experience and the control we maintain over our manufacturing processes.

All Humphrey Products’ pneumatic solenoid valve models are produced with precision machined or molded valve bodies, achieving close tolerance sealing surfaces and the industry’s lowest leak rates. In fact, many of our pneumatic solenoid valve models are deemed “bubble-tight” in application.
